cyntec provide series of high saturation, low DCR power chokes and passive components for high resolution TV application.

Product Application List -

CPU

Power Choke

Part Number	Dimension(mm)			Inductance Range (μH)	DCR Range (mΩ)	Heat Rating Cur. DC Amps. Idc (A)	Saturation Cur. DC Amps. Isat (A)
CMLE061E	6.724	7.241	1.5	0.12~10	3.0~175	2~19	3~29
HMLE32251E	3.2	2.5	1.5	0.47~2.2	13~88	3.7~7.0	3.7~8.1
SDER043T	4.0	4.0	3.0	1.0~120.0	12~1250	0.55~6.0	0.57~6.1
CMLB063T	6.8	7.3	3.0	0.1~33	0.81~284	1.8~40	2.0~60.2
CMLE063T	6.8	7.3	3.0	0.10~22.0	0.60~170	2.3~45	2.7~60
CMLS063T	6.8	7.3	3.0	0.1~6.8	0.8~105	2.8~33	6.3~70
CMLB104T	10.3	11.2	4.0	0.15~47	0.45~143	2.8~50	3.7~76
CMLE104T	10.3	11.5	4.0	0.22~1.0	0.6~2.3	22.5~50	28~72
CMLS104T	10.3	11.2	4.0	0.15~4.7	0.50~16.3	9.0~52	17~100
SDES064E	6.0	6.0	4.5	0.47~100	6.0~510	0.95~7.05	0.95~16.70
CMLS135T	12.8	13.8	5.0	0.47~4.7	1.05~15.0	10.8~38.0	23.0~75.0
CMLB135T	12.8	13.8	5.0	0.47~15	0.90~35	6.3~38.5	6.8~55.0
CMLB136T	12.8	13.8	6.0	8.2~150	13.5~347	2.2~11	2.7~16
CMLS136E	12.8	13.8	6.5	0.68~22	1.45~44	5.8~35	10~75

Product Application List -

RAM

Power Choke

Part Number	Dimension(mm)			Inductance Range (μH)	DCR Range (mΩ)	Heat Rating Cur. DC Amps. Idc (A)	Saturation Cur. DC Amps. Isat (A)
HMLQ32251T	3.2	2.5	1.0	4.7	200~240	1.5~1.7	1.8~2.0
HMLQ32251B	3.2	2.5	1.2	0.47~4.7	19~195	1.55~5.8	2.05~8.2
HMLE32251E	3.2	2.5	1.5	0.47~2.2	13~88	3.7~7.0	3.7~8.1
SDES064E	6.0	6.0	4.5	0.47~100	6.0~510	0.95~7.05	0.95~16.70
CMLS135T	12.8	13.8	5.0	0.47~4.7	1.05~15.0	10.8~38.0	23.0~75.0

Product Application List -

Display

Power Choke

Part Number	Dimension(mm)			Inductance Range (μH)	DCR Range (mΩ)	Heat Rating Cur. DC Amps. Idc (A)	Saturation Cur. DC Amps. Isat (A)
CMLE041B	4.45	4.75	1.2	0.22~6.8	7.2~355	1.5~13	2.3~15.5
CMLS041B	4.45	4.75	1.2	0.1~0.47	5.2~22.0	5.5~15	11.0~25
CMLB051B	5.4	5.75	1.2	0.68~4.7	22~163	2.0~6.6	2.9~8.9
CMLS051B	5.4	5.75	1.2	0.10~4.7	4.0~165	2.0~16.0	4.6~35.0
CMLE051E	5.4	5.75	1.5	0.12~10	3.2~170	1.9~18.0	2.7~29.0
HMLE32251E	3.2	2.5	1.5	0.47~2.2	13~88	3.7~7.0	3.7~8.1
CMLE061E	6.724	7.241	1.5	0.12~10	3.0~175	2~19	3~29
CMLB063T	6.8	7.3	3.0	0.1~33	0.81~284	1.8~40	2.0~60.2
CMLE063T	6.8	7.3	3.0	0.10~22.0	0.60~170	2.3~45	2.7~60
CMLS063T	6.8	7.3	3.0	0.1~6.8	0.8~105	2.8~33	6.3~70
SDER043T	4.0	4.0	3.0	1.0~120.0	12~1250	0.55~6.0	0.57~6.1
CMLB053T	4.9	5.2	3.0	0.10~6.8	2.0~115	2.8~28	3.2~38
CMLE053T	4.9	5.2	3.0	0.2~10.0	2.2~125	3.0~26.0	3.1~20.5
CMLE064T	6.8	7.6	4.0	0.15~0.42	0.66~1.55	21~40	19~50
CMLB104T	10.3	11.2	4.0	0.15~47	0.45~143	2.8~50	3.7~76
CMLE104T	10.3	11.5	4.0	0.22~1.0	0.6~2.3	22.5~50	28~72
CMLS104T	10.3	11.2	4.0	0.15~4.7	0.50~16.3	9.0~52	17~100
SDES064E	6.0	6.0	4.5	0.47~100	6.0~510	0.95~7.05	0.95~16.70
CMLB135T	12.8	13.8	5.0	0.47~15	0.90~35	6.3~38.5	6.8~55.0
CMLB136T	12.8	13.8	6.0	8.2~150	13.5~347	2.2~11	2.7~16
CMLS136E	12.8	13.8	6.5	0.68~22	1.45~44	5.8~35	10~75

Product Application List -

Connectivity

Product Application List -

Audio

Product Application List -

DC-DC

Power Choke

Part Number	Dimension(mm)			Inductance Range (μH)	DCR Range (mΩ)	Heat Rating Cur. DC Amps. Idc (A)	Saturation Cur. DC Amps. Isat (A)
HBLQ041T	4.3	4.3	1.0	0.47~10	17.5~336	1.5~7.5	1.65~8.0
HMLQ32251T	3.2	2.5	1.0	4.7	200~240	1.5~1.7	1.8~2.0
HMLQ32251B	3.2	2.5	1.2	0.47~4.7	19~195	1.55~5.8	2.05~8.2
CMLB041B	4.45	4.75	1.2	0.47~8.2	17.5~480	1.3~6.4	1.6~7.4
HBLE041B	4.3	4.3	1.2	0.47~10	15~240	1.6~9.2	1.4~9.4
CMLE041B	4.45	4.75	1.2	0.22~6.8	7.2~355	1.5~13	2.3~15.5
CMLS041B	4.45	4.75	1.2	0.1~0.47	5.2~22.0	5.5~15	11.0~25
CMLB051B	5.4	5.75	1.2	0.68~4.7	22~163	2.0~6.6	2.9~8.9
CMLS051B	5.4	5.75	1.2	0.10~4.7	4.0~165	2.0~16.0	4.6~35.0
HMLE25201D	2.5	2.0	1.4	2.2~4.7	69~213	1.4~2.5	1.7~3.3
HMLE32251E	3.2	2.5	1.5	0.47~2.2	13~88	3.7~7.0	3.7~8.1
CMLE051E	5.4	5.75	1.5	0.12~10	3.2~170	1.9~18.0	2.7~29.0
CMLE061E	6.724	7.241	1.5	0.12~10	3.0~175	2~19	3~29
HBLE041H	4.3	4.3	1.8	0.47~10	13~192	1.9~10	2.0~9.6
CMLB053T	4.9	5.2	3.0	0.10~6.8	2.0~115	2.8~28	3.2~38
CMLE053T	4.9	5.2	3.0	0.2~10.0	2.2~125	3.0~26.0	3.1~20.5
CMLB063T	6.8	7.3	3.0	0.1~33	0.81~284	1.8~40	2.0~60.2
CMLE063T	6.8	7.3	3.0	0.10~22.0	0.60~170	2.3~45	2.7~60
CMLS063T	6.8	7.3	3.0	0.1~6.8	0.8~105	2.8~33	6.3~70
SDER043T	4.0	4.0	3.0	1.0~120.0	12~1250	0.55~6.0	0.57~6.1
CMLE064T	6.8	7.6	4.0	0.15~0.42	0.66~1.55	21~40	19~50
CMLB104T	10.3	11.2	4.0	0.15~47	0.45~143	2.8~50	3.7~76
CMLE104T	10.3	11.5	4.0	0.22~1.0	0.6~2.3	22.5~50	28~72
CMLS104T	10.3	11.2	4.0	0.15~4.7	0.50~16.3	9.0~52	17~100
SDES064E	6.0	6.0	4.5	0.47~100	6.0~510	0.95~7.05	0.95~16.70
CMLB135T	12.8	13.8	5.0	0.47~15	0.90~35	6.3~38.5	6.8~55.0
CMLS135T	12.8	13.8	5.0	0.47~4.7	1.05~15.0	10.8~38.0	23.0~75.0
CMLB065T	6.8	7.4	5.0	0.47~10.0	3.21~54	4.3~20.2	4.7~24.0
CMLB136T	12.8	13.8	6.0	8.2~150	13.5~347	2.2~11	2.7~16
CMLS136E	12.8	13.8	6.5	0.68~22	1.45~44	5.8~35	10~75

Power Module

Part Number

Dimension(mm)

Input Voltage(V)

Output Voltage(V)

MUN12AD03-SM

6.0

3.5

4.5~16.0

0.6~5.0

MUN24AD03-SM

6.0

3.5

4.5~34.0

5.0~12.0

Product Application List -

General use

Chip Resistor

Part Number

Dimension

Metric(mm)

Inch(mil)

Dim. Power Rating(W)

Resistance Values(Ω)

Resistance Tolerance

TCR (ppm/°C)

RR0306S

0603

0201

1/20W

1~10M

±0.5%(D) ±1%(F)

±200

RR0510

1005

0402

1/16W

1~10M

±0.5%(D) ±1%(F)

±25

RR0510SE

1005

0402

1/16W

10~1M

±1%(F)

±200

Product Application List -

AC-DC

Power Choke

Part Number	Dimension(mm)			Inductance Range (μH)	DCR Range (mΩ)	Heat Rating Cur. DC Amps. Idc (A)	Saturation Cur. DC Amps. Isat (A)
SDER043T	4.0	4.0	3.0	1.0~120.0	12~1250	0.55~6.0	0.57~6.1
